Pre Order
Used Glue dispenser machine PANASONIC HDF NM-DC10
SKU : M2K000081
0 Sold
Quantity
Short Description
Rated voltage
3 phase AC 200 V ±10 V
Frequency
50/60 Hz
Rated capacity
4.5 kVA Main unit: 2.0 kVA
Ambient temperature controller (Option)
2.5 kVA
Brands: Panasonic
Product description
Specification
Electric Source:
Rated voltage: 3 phase AC 200 V ±10 V
Frequency: 50/60 Hz
Rated capacity: 4.5 kVA Main unit: 2.0 kVA
Ambient temperature controller (Option): 2.5 kVA
The main machine has power supply for optional units.
Pneumatic Source:
Supply air pressure: 0.5 MPa
Air consumption: 40 L/min (A. N. R.)
Dimensions:
NM-DC10: W 1 590 mm × D 770 mm × H 1 500 mm (Not including signal tower and monitor)
NM-DC15: W 1 930 mm × D 1 082 mm × H 1 500 mm (Not including signal tower and monitor)
